| 牌号 | AN004 |
|---|---|
| 销售方式 | 品牌经销 |
| 用途级别 | 瓶盖专用料 |
| 厂家(产地) | 伊士曼化学 |
| 加工级别 | 注塑级 |
| 特性级别 | 抗化学性,耐高温 |
应用/用途
化妆品罐帽
化妆品瓶
化妆品/个人护理包装
香水胶囊
香水包装
口红容器
个人保健瓶
产品属性
容易挤出，切，打印，和海豹
有效的屏障特性
优良的耐化学性
优秀的清晰度
优秀的着色
良好的冲击强度
高刚度
高光泽外观
韧性
| Product Data Sheet Eastar™ Copolyester AN004, Natural | ||||||||
| ||||||||
| Typical Properties | ||||||||
| Propertya | Testb Method | Typical Value, Unitsc | ||||||
| Specific Gravity | D 792 | 1.2 | ||||||
| Mold Shrinkage Parallel to Flow, 3.2-mm (0.125-in.) thickness | D 955 | 0.002-0.006 mm/mm (0.002-0.006 in./in.) | ||||||
| Mechanical Properties | ||||||||
| Tensile Stress @ Yield | D 638 | 47 MPa (6900 psi) | ||||||
| Tensile Stress @ Break | D 638 | 51 MPa (7400 psi) | ||||||
| Elongation @ Yield | D 638 | 5% | ||||||
| Elongation @ Break | D 638 | 320% | ||||||
| Flexural Modulus | D 790 | 2000 MPa (2.9 x 105psi ) | ||||||
| Flexural Yield Strength | D 790 | 69 MPa (10000 psi) | ||||||
| Rockwell Hardness, R Scale | D 785 | 103 | ||||||
| Izod Impact Strength, Notched | ||||||||
| D 256 | 80 J/m (1.5 ft·lbf/in.) | ||||||
| D 256 | 40 J/m (0.7 ft·lbf/in.) | ||||||
| Impact Strength, Unnotched | ||||||||
| D 4812 | NB | ||||||
| D 4812 | NB | ||||||
| Impact Resistance (Puncture), Energy @ Max. Load | ||||||||
| D 3763 | 42 J (31 ft·lbf) | ||||||
| D 3763 | 48 J (35 ft·lbf) | ||||||
| Mechanical Properties (ISO Method) | ||||||||
| Tensile Strength @ Yield | ISO 527 | 47 MPa | ||||||
| Tensile Strength @ Break | ISO 527 | 46 MPa | ||||||
| Elongation @ Yield | ISO 527 | 4% | ||||||
| Elongation @ Break | ISO 527 | 200% | ||||||
| Tensile Modulus | ISO 527 | 1800 MPa | ||||||
| Flexural Modulus | ISO 178 | 1850 MPa | ||||||
| Flexural Strength | ISO 178 | 65 MPa | ||||||
| Izod Impact Strength, Notched | ||||||||
| ISO 180 | 7.8 kJ/m2 | ||||||
| ISO 180 | 4.8 kJ/m2 | ||||||
| Thermal Properties | ||||||||
| Deflection Temperature | ||||||||
| D 648 | 73°C (164°F) | ||||||
| D 648 | 65°C (149°F) | ||||||
| Optical Properties | ||||||||
| Haze | D 1003 | 0.3% | ||||||
| Regular Transmittance | D 1003 | 89% | ||||||
| Total Transmittance | D 1003 | 91% | ||||||
| Typical Processing Conditions | ||||||||
| Drying Temperature | 70°C (160°F) | |||||||
| Drying Time | 3 hrs | |||||||
| Processing Melt Temperature | 230-280°C (450-530°F) | |||||||
| Mold Temperature | 15-30°C (60-80°F) | |||||||
