吸泥胶管SLURRY SUCTION HOSE
内胶层:天然、顺丁、丁苯橡胶
外胶层：天然、氯丁橡胶
安全系数：3:1
增强层：多层高强度聚酯帘子线
工作温度：-20℃~80℃
用途：安装于挖泥船的泥泵与铰刀之间，承受工作负压，抽吸泥沙。内胶层或者增强层嵌有耐磨钢环，适用于输送石灰石、花岗石、珊瑚、矿石等大粒坚硬物质。
Tube:NR,BR,SBR
Reinforcement:high tensile strength fabrics
Cover:NR,CR
Ideal working temperature:-20℃~80℃
Safty factor:3:1
Application:installed in between the pump and cutter of thedredger,suction the slurry.suction hose and armored hose with HBsteel ring in,suitable for limestone,granite,coral,and mineraletc
规格/size | 内径/I.D | 压力/W.P. | 长度/length |
8inch | 200mm | 15bar~20bar | 11.8m |
10inch | 250mm | ||
12inch | 300mm | ||
16inch | 400mm | ||
20inch | 500mm | ||
24inch | 600mm | ||
26inch | 650mm | ||
30inch | 750mm | ||
32inch | 800mm | ||
34inch | 850mm | ||
备注：内径900mm&1200mm,等其他技术数据可根据要求定做 NOTE:ID900mm&1200mm,other parameters are by yourre | |||
